Pipe Blasting Machine

Pipe Blasting Machine Specification

Connectivity Options
Standard electric connections, Optional remote monitoring

Noise Level
Less than 85 dB db

Frequency
50 Hz Hertz (HZ)

Voltage
380V / 415V (3 Phase) Volt (v)

Accuracy
High, consistent blast coverage PSI

Frame Type
Rugged welded steel frame

Power Rating
20 HP

Production Capacity
3-10 pieces/hour Kg

Country Of Origin
india

Operating Temperature
5C to 45C Celsius (oC)

Machine Type
Airless

Lubricating System
Automatic Lubrication

Control System
Fully Automatic

Features
Heavy duty body, Multiple nozzle configuration, Dust collection system

Motor Power
15 kW (main blast wheel motor) Kilowatt (kW)

Drive
Electric Motor Drive

Cooling System
Air cooled

Model No
PBM-1200

Product Type
Other

Technology
Other

Power Source
Electricity

Power
12-20 kW (depending on model size) Watt (w)

Pressure
6-8 bar (recommended) Bar

Surface Treatment
Other

Dimension (L*W*H)
3600 x 1500 x 2200 mm Millimeter (mm)

Weight (kg)
Approx. 1800-2500 kg (model dependent) Kilograms (kg)

Color
Blue & White

Warranty
1 year

Usage & Applications
External & internal pipe cleaning, rust removal, pipe surface preparation

Input Control
Touch Panel Interface

Installation Type
Floor mounted

Chamber Material
Manganese Steel Lined

Abrasive Media Type
Steel shot / Grit / Sand

Conveyor Type
Roller Support or Skid Conveyor

Exhaust Fan Power
2.2 kW

Working Speed
Variable (up to 1.5 m/min)

Maintenance Access
Easy access doors for maintenance

Number of Blast Wheels
2-4 Wheels (based on model)

Maximum Pipe Weight Capacity
Upto 2500 kg

Pipe Diameter Range
60 mm to 1200 mm

Service Support
On-site commissioning & training

Safety Features
Emergency stop, Door interlocks, Overload protection

Dust Collector Type
Cartridge Filter or Baghouse

Pipe Length Capacity
1500 mm to 12000 mm

Pipe Blasting Machine Trade Information

Minimum Order Quantity
1 Number

Delivery Time
7 Week

About Pipe Blasting Machine

Discover the preeminent Pipe Blasting Machine-crafted for superior pipe cleaning and surface preparation. Designed with an astonishing blend of value and precision, this equipment offers ephemeral yet highly consistent and accurate blast coverage. Suitable for pipe diameters from 60 mm to 1200 mm, it supports lengths up to 12,000 mm and weights to 2500 kg. Its manganese steel lined chamber, variable speeds, automatic lubrication, and advanced PLC control guarantee both reliability and control. Choose this machine for its rugged build, exceptional safety features, and unrivaled efficiency in every order.

Advanced Features and Versatile Application

The Pipe Blasting Machine stands out with its heavy-duty body, multiple nozzle configurations, and user-friendly touch panel interface. It utilizes automatic grit blasting for precise external and internal pipe cleaning, rust removal, and optimal surface preparation. Maintenance is hassle-free, with easy-access doors and robust dust collection. Engineered for reliability, it features high accuracy, a rugged welded steel frame, and superior noise control-ideal for exporters, manufacturers, and suppliers alike.

Superior Supply Chain and Export Services

Our Pipe Blasting Machines are available for prompt delivery with dependable transport services via main Indian ports. With a supply ability of 3-10 pieces per hour, shipments match your proposal amount and are handled efficiently, ensuring timely dispatch and safe arrival. Freight options are fully flexible to maximize value, and our export market spans multiple regions, backed by meticulous support and professional logistics.

FAQ's of Pipe Blasting Machine:

Q: How does the Pipe Blasting Machine ensure superior cleaning performance?

A: The machine uses adjustable blast wheels and multiple nozzle configurations with steel shot, grit, or sand media, powered by a robust electric drive. Its precise PLC control and high-accuracy blast coverage guarantee consistently excellent cleaning results on both internal and external pipe surfaces.

Q: What safety features are integrated into the Pipe Blasting Machine?

A: Safety is paramount, with emergency stop buttons, door interlocks, and overload protection designed into every model. Maintenance access is secured through easy-access doors, ensuring operator safety during servicing.

Q: Where can the Pipe Blasting Machine be used effectively?

A: This equipment is ideal for pipe manufacturing plants, exporters, and surface treatment facilities requiring efficient pipe cleaning, rust removal, and surface preparation for pipes of varying diameters and lengths.

Q: What is the process for installing and commissioning the Pipe Blasting Machine?

A: Installation is floor-mounted and supported by our on-site commissioning services. We provide thorough training to ensure smooth setup and operation, minimizing downtime and optimizing productivity.

Q: How does the dust collection system in the machine operate?

A: The machine features a choice of cartridge filter or baghouse dust collectors. These systems efficiently capture blasting debris, ensuring a cleaner working environment and reducing maintenance frequency.
