Aluminum section cleaning shot blasting machine

Name: Aluminum section cleaning shot blasting machine
Brand: ADL BLASTEK INDUSTRIES
Price: 1500000.0 INR
Availability: InStock

Price 1500000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Aluminum section cleaning shot blasting machine Specification

Connectivity Options
Standard electric interface

Motor Power
4-5 kW (per blast wheel)

Frame Type
Heavy Duty Welded Frame

Drive
Direct Drive Blast Wheel

Operating Temperature
5-45C

Cooling System
Air Cooling

Machine Type
Section Cleaning Machine

Production Capacity
Up to 20-30 m/min

Power Rating
3-Phase / 380V / 50Hz

Features
High operational efficiency, Low maintenance, Durable structure

Voltage
380V

Frequency
50Hz

Lubricating System
Automatic lubrication

Model No
ASC-1200

Accuracy
High

Noise Level
<85 dB(A)

Product Type
Shot Blasting Machine

Technology
Shot Blasting

Power Source
Electric

Operating Type
Automatic

Power
12-20 kW (Depending on model)

Pressure
0.5-0.8 MPa

Surface Treatment
Cleaning, Deburring, Descaling

Dimension (L*W*H)
Customizable (Typical: 6000 x 1800 x 2200 mm)

Weight (kg)
Approx. 3500 kg

Color
Blue & Grey

Usage & Applications
Cleaning of aluminum profiles, sections, and extrusions

Loading/Unloading System
Manual/Semi-Automatic optional

Transportability
Static installation

Service Support
Available

CE Certified
Yes

Dust Collector Type
Cartridge or Bag Filter cyclone system

Abrasive Hopper Capacity
150-250 kg

Finish Quality
SA 2.5-3 as per ISO 8501-1

Maintenance Access
Large access doors for easy maintenance

Temperature Resistance
Up to 60C

Inlet/Outlet Height
Adjustable, up to 400 mm

Number of Blast Wheels
2-4 (Depending on capacity)

Door Type
Automatic/Manual (Depends on model)

Working Speed
10-30 m/min adjustable

Blasting Chamber Lining
Mn wear-resistant lining

Safety Systems
Emergency stop, interlocks, overload protection

Conveyor Type
Roller Conveyor

Abrasive Type
Steel Shot / Grit

About Aluminum section cleaning shot blasting machine

The Aluminum Section Cleaning Shot Blasting Machine, Model ASC-1200, offers world-class cleaning, deburring, and descaling for aluminum profiles with noteworthy precision. Featuring 2-4 venerable blast wheels and a robust roller conveyor, this customizable machine efficiently handles sections up to 400 mm in height. Its adjustable working speed (10-30 m/min), advanced dust collectors, and durable Mn-lined chamber ensure longevity and safety. Ephemeral deals are ending soon-try now for optimum results! CE certified, static installation, and automatic PLC controls provide superior usability and protection for demanding industrial environments.

Versatile Industrial Shot Blasting Solution

The Aluminum Section Cleaning Shot Blasting Machine excels in cleaning, deburring, and descaling aluminum profiles. Perfect for commercial fabrication shops, extrusion plants, and metal finishing units, this robust equipment delivers high operational efficiency and minimal maintenance. Its heavy-duty welded frame, automatic lubrication system, and advanced safety features ensure continuous, reliable operation, making it a premier choice for diverse aluminum processing applications across construction, transportation, and architectural industries.

Export-Ready, Sample Access, and Reliable Supply

We offer sample availability to demonstrate machine proficiency before bulk orders, catering to a discerning export market. With supply ability tailored to volume requirements, each machine is shipped through major FOB ports in India, using secure, industry-standard packaging for safe arrival. Enjoy the lowest price and proven reliability from an established exporter, manufacturer, and supplier. Connect now to access world-class technology meeting your business needs at competitive terms.

FAQ's of Aluminum section cleaning shot blasting machine:

Q: How does the shot blasting process improve aluminum section cleaning?

A: The shot blasting process removes surface contaminants, scales, and oxidation from aluminum sections efficiently, providing a cleaner and more uniform surface ideal for subsequent treatments such as painting or coating.

Q: What safety features are included in the machine?

A: This machine is equipped with emergency stop buttons, interlocks, overload protection, and large maintenance doors, ensuring user safety and easy access for regular maintenance.

Q: Where can this machine be effectively utilized?

A: It is ideal for industries engaged in the fabrication, finishing, or extrusion of aluminum profiles-such as construction, transportation, and architectural components manufacturing.

Q: What advantages does this model offer over traditional cleaning methods?

A: It delivers high-speed, consistent cleaning with reduced manual labor, minimal downtime due to automatic lubrication, and ensures a high-quality SA 2.5-3 surface finish as per ISO 8501-1 standards.

Q: When is the best time to try or purchase this equipment?

A: Limited-time, ephemeral offers are ending soon-contact us to try the machine or secure your unit at exclusive introductory prices before the deal expires.
