Industrial roller shot blasting machine

Industrial roller shot blasting machine Specification

Model No
IRSBM-9000

Production Capacity
Up to 1200 m2/h

Drive
Roller Driven Conveyor

Frequency
50 Hz

Cooling System
Air Cooling

Power Rating
18 kW

Connectivity Options
Standard Electrical Interface

Motor Power
7.5 kW per Turbine

Noise Level
85 dB

Operating Temperature
Up to 45C

Features
Rugged Construction, Uniform Cleaning, Efficient Abrasive Recycling

Machine Type
Industrial Roller Shot Blasting

Frame Type
Heavy Duty Welded Frame

Accuracy
High Surface Cleanliness Fulfilling Sa2.5/Sa3 Standard

Lubricating System
Centralized Automatic Lubrication

Voltage
380 V

Product Type
Roller Conveyor Shot Blasting Machine

Technology
Shot Blasting

Power Source
Electric

Operating Type
Automatic

Power
18 kW

Pressure
0.8 MPa

Surface Treatment
Blasting and Cleaning

Dimension (L*W*H)
9000 x 3000 x 4500 mm

Weight (kg)
14000 kg

Color
Industrial Grey

Usage & Applications
Surface cleaning, de-scaling, and preparation of metal sheets, structures, and profiles

Safety Features
Emergency Stop, Interlocked Doors, Safety Guards

Cycle Time
Adjustable to Application

Electrical Protection
Overload & Short Circuit Protection

Maximum Workpiece Size
1200 mm (Width)

Min Workpiece Size
100 mm (Width)

Abrasive Type
Steel Shot / Grit

Dust Collector Type
Cartridge Filter Type with Pulse Jet Cleaning

Installation Service
Available

Maintenance Access
Large Service Doors with Safety Interlocks

Customization Option
Available on Request

Working Speed
0.5-3 m/min Adjustable

Conveyor Height
700 mm (adjustable)

Shipping Condition
Knocked Down/Assembled as Required

Number of Blast Turbines
4

Standards Compliance
CE and ISO Certified

Usage Environment
Indoor Industrial Use

Abrasive Flow Rate
240 kg/min

About Industrial roller shot blasting machine

Elevate your industrial processes with the valiant IRSBM-9000 Industrial Roller Shot Blasting Machine. Designed for astounding performance and valorous reliability, this model features a working speed of 0.5-3 m/min (adjustable) and four robust blast turbines, efficiently recycling steel shot or grit abrasives at 240 kg/min. The heavy-duty welded frame and centralized lubrication guarantee rugged construction and long life. Buy online or request advance purchase today-installation service and worldwide shipping (knocked down or assembled) are available. Meet top-tier surface cleanliness standards with high production accuracy and automatic PLC controls. Order from India's trusted exporter, manufacturer, and supplier.

Application Versatility and Material Advantages

The IRSBM-9000 Industrial Roller Shot Blasting Machine excels in surface cleaning, de-scaling, and preparation of metal sheets, structures, and profiles. Its heavy-duty welded frame ensures longevity, while efficient abrasive recycling and uniform cleaning fulfill Sa2.5/Sa3 standards. Adaptable for a range of metals, it offers remarkable accuracy, consistent results, and rapid throughput, making it ideal for fabrication shops, steel plants, and manufacturing facilities demanding superior finish and productivity.

Payment Terms and Rapid Order Fulfillment

Advance purchase options and flexible payment terms make acquiring the IRSBM-9000 straightforward. Enjoy quick dispatch and professional order processing for both standard and customized configurations. Your order completion is prioritized, with delivery times designed to match project schedules. Samples are available on request to demonstrate performance and assure suitability before purchase, ensuring satisfaction with every transaction.

FAQ's of Industrial roller shot blasting machine:

Q: How can I order the IRSBM-9000 Industrial Roller Shot Blasting Machine?

A: You can buy online, place an advance purchase, or contact our team directly for customized orders. The machine can be shipped assembled or knocked down, according to your requirements.

Q: What are the main application areas for this shot blasting machine?

A: The IRSBM-9000 is ideal for surface cleaning, de-scaling, and preparation of metal sheets, structural components, and profiles across various industrial environments.

Q: What safety and maintenance features are included?

A: The machine features safety guards, emergency stop functions, interlocked doors, large service doors with safety interlocks, as well as overload and short circuit protection. Maintenance is streamlined through accessible service points and centralized automatic lubrication.

Q: When will my order be processed and dispatched?

A: Orders are processed promptly upon confirmation. Quick dispatch and efficient order completion are hallmarks of our service to ensure minimal lead times and on-time delivery.

Q: What are the advantages of the IRSBM-9000 over traditional cleaning methods?

A: This model delivers uniform cleaning, preserves material integrity, efficiently recycles abrasives, and achieves a high surface cleanliness standard (Sa2.5/Sa3), which manual or chemical cleaning often cannot match.
