ADL BLASTEK ROLLER CONVEYOR MACHINE

ADL BLASTEK ROLLER CONVEYOR MACHINE Specification

Country Of Origin
india

Accuracy
99 %

Production Capacity
Up to 7 m/min (depending on workpiece) Pcs/hr

Lubricating System
Centralized Automatic Lubrication

Frame Type
Heavy Duty Welded Frame

Cooling System
Air Cooled

Motor Power
7.5 kW (per blast wheel) Kilowatt (kW)

Drive
Electric Roller Drive

Connectivity Options
User Interface Panel, PLC Diagnostic Ports

Frequency
50 Hz Hertz (HZ)

Power Rating
22-37 kW (Model Dependent)

Features
Efficient abrasive recycling, low energy consumption, robust construction, wear-resistant liners

Voltage
380-415V, 3 Phase AC Volt (v)

Operating Temperature
5-45C Celsius (oC)

Machine Type
airless

Control System
PLC

Model No
Blastek RC-Series

Noise Level
85 dB(A) db

Product Type
Other

Technology
Other

Power Source
Electricity

Operating Type
Automatic

Power
22 kW Watt (w)

Pressure
Adjustable up to 6 bar (87 psi) PSI

Surface Treatment
Other

Dimension (L*W*H)
Approx. 7000 x 4600 x 5000 mm Millimeter (mm)

Weight (kg)
Approx. 8200 kg Kilograms (kg)

Color
Blue & Grey

Warranty
1 year

Usage & Applications
Cleaning, surface preparation, rust & scale removal for sheets, plates, structural steel, pipes, and profiles

Hourly Throughput
Up to 18 Tons/Hour

Conveyor Height
800 mm (Adjustable)

Chamber Material
Manganese Steel Liners

Abrasive Type
Steel Shots or Grit

Blast Wheel Quantity
4 to 8 (Model Based)

Dust Collector Type
Cartridge/Bag Filter

Maximum Workpiece Width
1500 mm

Abrasive Recycling System
Elevator, Separator & Screw Conveyor

Entry & Exit Sealing
Heavy Rubber Curtains

Safety Features
Emergency Stop, Overload Protection, Interlocked Doors

ADL BLASTEK ROLLER CONVEYOR MACHINE Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
7 Week

About ADL BLASTEK ROLLER CONVEYOR MACHINE

Experience the Elite power of the ADL BLASTEK Roller Conveyor Machine-a new release that's now available for sale. Engineered for both remarkable efficiency and formidable strength, this machine accommodates 4 to 8 blast wheels (model based), expertly handling steel shots or grit for superior surface treatment. With an adjustable conveyor height and a max workpiece width of 1500mm, it ensures adaptability and precision with 0.5mm accuracy. Robust manganese steel liners, formidable safety features, and a centralized automatic lubrication system guarantee elite durability for continuous industrial use.

Versatile Applications and Competitive Edge

The ADL BLASTEK Roller Conveyor Machine is designed for both specific and general industrial uses, excelling in surface cleaning, preparation, rust removal, and scale elimination for sheets, plates, pipes, and structural steel. Its shot-blasted finish ensures a pristine surface, ready for fabrication or coating. The formidable abrasive recycling system, robust construction, and high hourly throughput deliver a competitive advantage with consistently efficient, cost-effective performance.

Export Markets, Shipment, and Payment Terms

The ADL BLASTEK Roller Conveyor Machine is shipped to major international markets, with stock ready for timely dispatch. Shipments typically leave from major Indian FOB ports, ensuring reliable export logistics. Payment terms are flexible, catering to global clients' requirements, serving as a preferred exporter, manufacturer, and supplier. Our well-managed shipment process guarantees that shipped goods arrive on schedule, supporting seamless industrial operations worldwide.

FAQ's of ADL BLASTEK ROLLER CONVEYOR MACHINE:

Q: How does the ADL BLASTEK Roller Conveyor Machine improve industrial surface cleaning processes?

A: The machine enhances surface cleaning through its powerful shot blasting technology, automatic operation, adjustable pressure, and efficient abrasive recycling system. These features ensure thorough removal of rust, scale, and contaminants on a variety of workpiece surfaces such as steel plates, pipes, and profiles.

Q: What safety features are integrated into the ADL BLASTEK Roller Conveyor Machine?

A: It is equipped with emergency stop functions, overload protection, interlocked doors, and heavy rubber curtains for entry and exit, ensuring operator safety and preventing accidental exposure to blasting operations.

Q: Where can the ADL BLASTEK Roller Conveyor Machine be used?

A: This machine is suitable for fabrication shops, steel mills, shipyards, and other industrial settings where surface cleaning, rust removal, or preparation is needed before painting or coating.

Q: When can customers expect shipment after placing an order?

A: With stock ready, most shipments can be dispatched promptly upon order confirmation, subject to payment terms and shipping arrangements with the customer.

Q: What are the main benefits of using a PLC-controlled system in this machine?

A: The PLC-controlled system ensures precise, reliable automation, user-friendly diagnostics, and simplifies operation, resulting in consistent results and reduced downtime.
