Send Inquirypeb structure shot blasting machine
Price 1500000.0 INR/ Unit
peb structure shot blasting machine Specification
- Motor Power
- 20 Horsepower (HP)
- Noise Level
- 85 db
- Control System
- Fully Automatic, PLC
- Model No
- ADL-BT-ARC
- Machine Type
- Airless
- Country Of Origin
- India
- Accuracy
- 99 %
- Voltage
- 415 Volt (v)
- Product Type
- Other
- Technology
- Other
- Power Source
- Electricity
- Operating Type
- Automatic
- Power
- 30 Horsepower (HP)
- Pressure
- 5-6 Bar
- Surface Treatment
- Painted
- Dimension (L*W*H)
- 1500x500x600 Millimeter (mm)
- Weight (kg)
- 15 Tonne
- Color
- Blue
- Warranty
- 1 year
peb structure shot blasting machine Trade Information
- Minimum Order Quantity
- 1 Number
- Delivery Time
- 6 Week
About peb structure shot blasting machine
1. Loading and feeding
Steel plates or fabricated components are placed on powered rollers, which move the material into the blasting chamber at a controlled speed.
High-speed turbine wheels (blast wheels) throw steel shot or grit onto the workpiece. The impact removes rust, scale, and surface contamination.
Used shot falls into a collection hopper and is transported by screw conveyors and a bucket elevator back toward the separator.
The separator removes dust, broken abrasive, and other unwanted particles. Reusable steel shot returns to the blast wheels.
The workpiece exits through the outlet, where brushes and air blow-off remove remaining shot. The cleaned surface is ready for inspection, painting, or coating
