Hanger type shot blast machines designed and built as fully integrated blast cleaning systems to handle large/small or more fragile castings than barrel/table type machines. They provide a cost-effective solution for batch cleaning.
Hanger typeMachine consists of horizontal door with a rotating hanger type work/job handling system. This hanger is directly mounted on the door of the machine and itrotates on its own axis, drive unit of this hanger is provided outside the door. This hanger swings out as the door is opened, making the full area easily approachable for loading and unloading of the components. For loading the components, door of the machine is opened manually & components to be blasted are hanged one by one on to the door hanger and the door of the machineis closed.
After thistwo no's of Blast wheel units which are strategically placed on the Blastcabinet, is started. Blast wheels will fire the abrasive at high velocity onthe components hanged on the hangers and rotating in clockwise and Anti-clockwise direction and blast cleans them thoroughly. Bi-directional rotational mechanism of hanger ensures that each and every portion of the component will get exposed to the blast stream for through cleaning. The arrangement ofthe blast wheel ensures optimum blast cleaning and maximum utilization of theabrasive energy. After the required blasting cycle, blast wheel unit shuts off and door of the machine is opened manuallyfor unloading of the components.
Specification
Number of Doors | Single Door |
Brand | Adl Blastek |
Power Required | 14.5 HP |
Capacity | 10-15 ton/day |
Voltage (V) | 415 V |
Driven Type | Belt Driven Wheel |
No. Of Blast Wheels | 2 |
Wheel Size (inch) | 12.5" X 2.5" |
Model Number | BT-SPH-1 |
Load Carrying Capacity Of Hanger (kg) | 300 Kg |
Automatic Grade | Automatic |
Blast Wheel Power | 5 HP |
No. of Door with Hanger Hook | 1 |
Diameter and Height Of Hanger Turning Meter | 600 x 700 mm |
